Infrared Light Curtain
Created with Pixso.

ELHNC1200 Infrared Light Curtain 18m Range 25mm Detection

ELHNC1200 Infrared Light Curtain 18m Range 25mm Detection

ELHNC1200 Infrared Light Curtain 18m Range 25mm Detection

Brand Name: CET
Model Number: ELHN(C)
Detail Information
Product Description
Detail Information
Highlight:

infrared vehicle detector

,

light curtain vehicle sensor

,

vehicle detection light curtain

Product Description
LHNC Grating Vehicle Detector
The LHNC grating vehicle detector provides reliable vehicle separation with up to 100% accuracy. Featuring electric heated tempered glass and durable construction, it's designed for demanding industrial applications.
Technical Specifications
Model Test Distance Minimum Detectable Optical Axes Height Response Time Size
ELHNC1200 18m 25mm 48 1200mm 15ms 1280mm
Key Features
  • Construction: Black anodized aluminum alloy shell with electric heated tempered glass window
  • Protection: IEC IP67 rated for harsh environments
  • Durability: Vibration resistant (10-50Hz for 1 hour in X, Y, Z directions)
  • Detection Range: 600-2360mm
  • Longevity: 10+ year service life with MTBF ≥ 100,000 hours
Product Overview
The LHNC grating vehicle detector represents an upgraded version specifically engineered for vehicle separation and detection in ETC standard lanes. Its simplified wiring, compact design, and easy installation make it ideal for modern traffic management systems while requiring minimal maintenance.
