Vibrating Wire Surface Strain Gauge (Standard)

Name: Vibrating Wire Surface Strain Gauge (Standard)
Brand: Chengdu Enviko Technology Co.,Ltd
SKU: SK-SD
Price: Negotiable USD
Availability: InStock

Brand Name:	Enviko
Model Number:	SK-SD

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Description

Overview

The Enviko SK-SD vibrating wire surface strain gauge monitors strain on pipelines, steel structures, steel plates and bridges. Its two end blocks can be arc-welded or bolted to a steel surface. On concrete, the gauge is fixed with short anchor bars set in drilled holes. A built-in temperature sensor records ambient temperature.

Key Features

Flexible mounting: arc welding or bolting on steel, anchoring on concrete
Compact size: 174 × 26 × 38 mm
100 mm gauge length
Built-in temperature sensor
Works with standard vibrating wire readouts and data loggers

Applications

Steel structures and steel plates
Pipelines
Bridges
Concrete surfaces (anchored installation)

Specifications

Parameter	Specification
Model	SK-SD100
Measuring range	3000 με (±1500 με)
Gauge length	100 mm
Elastic modulus	100–150 MPa
Resolution	0.5% FS
Non-linearity	≤ 0.5% FS (linear); ≤ 0.1% FS (polynomial)
Accuracy	±0.1% FS
Temperature range	−20 °C to +80 °C
Temperature accuracy	±0.1 °C
Water pressure resistance	0.5 MPa
Insulation resistance	≥ 50 MΩ
Dimensions	174 × 26 × 38 mm
