Vibrating Wire Strain Gauge (General Purpose)

Name: Vibrating Wire Strain Gauge (General Purpose)
Brand: Chengdu Enviko Technology Co.,Ltd
SKU: SK-GD
Price: Negotiable USD
Availability: InStock

Brand Name:	Enviko
Model Number:	SK-GD

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Description

Overview

The Enviko SK-GD general-purpose vibrating wire strain gauge monitors stress and strain in beams, piles and pile foundations, supports, hydraulic structures, linings, piers and bedrock of concrete structures. It is also used for strain monitoring of steel structures, steel plates and bridges. A built-in temperature sensor records ambient temperature.

Key Features

One gauge for both concrete and steel structures
Compact size: 174 × 26 × 38 mm
100 mm gauge length
Built-in temperature sensor
Works with standard vibrating wire readouts and data loggers

Applications

Piles and pile foundations
Beams, supports and piers
Hydraulic structures and tunnel linings
Bedrock
Steel structures, steel plates and bridges

Specifications

Parameter	Specification
Model	SK-GD100
Measuring range	3000 με (±1500 με)
Gauge length	100 mm
Elastic modulus	100–150 MPa
Resolution	0.5% FS
Non-linearity	≤ 0.5% FS (linear); ≤ 0.1% FS (polynomial)
Accuracy	±0.1% FS
Temperature range	−20 °C to +80 °C
Temperature accuracy	±0.1 °C
Water pressure resistance	0.5 MPa
Insulation resistance	≥ 50 MΩ
Dimensions	174 × 26 × 38 mm
